Manufacturer Base Twist Lock Power Cord NEMA L5-20P 3-Prong 20-Amp 125-Volt Generator Locking Type, UL listed

Samples date: 7 Days,Free with freight collect
MOQ:1000 Pcs
Production order shipping date:20-25 days
Shipping Terms: By Air, Sea
Payment Terms: Wire Transfer, Paypal
Packing:Export cartons,pallets

Tags:

Twist Lock Power Cord NEMA L5-20P

Twist Lock Power Cord NEMA L5-20P 20A, 125V, 3 prong plug molded with custom long ,color PVC, rubber or TPE cable.

Plug type: L5-20P twist lock plug
Standard:NEMA L5-20P
Approvals:UL, cUL
Electricity:20A, 125V
Number of Poles and Wires:2 pole 3 wires
Cable length:1.0 meter, 1.5m, 1.8m,custom length
End Options:Locking Socket,IEC 320 receptacles,ROJ, Termination
Quality System:ISO9001:2008

Color:White and black are normal,Custom color
Outer Mold Material:PVC,Rubber
Plug Insert Material:PBT,ABS
Blade Material:Nickel coated Brass
Cable Specifications:Standard and custom made
Wire Outject Material:PVC,Rubber,TPE,Textile
Environmental Certifications:RoHS, REACH, PAHS
Model Number:XH1520P-A

Plug Standard America NEMA L5-20P plug Maximum Electric Current rating 20 Amps Maximum Voltage 125-Volt Number of Poles and Wires 2 poles, 3 wires Grounded Locking Type Plug, Connector Standards Twsit locking receptacles, IEC 60320 (320) C-13, C-13 Locking, C-19, C-19 Locking, C-5, C-15 connectors, Unterminated.

Available Opposite End

Normal Stripped, Splitter and ROJ

We manufacturers and supplies Twist Lock Power Cord NEMA L5-20P,custom color,the other end can be stipped,ROJ with custom length.

Common Termination

Twist Lock Power Cord NEMA L5-20P, one end is molded with NEMA Locking standard sheet plugs, the opposite could be terminated with types of terminals such as grounding rings terminals ,fork with heat shrink or nylone insulated.

IEC 60320 Connectors

Twist Lock Power Cord NEMA L5-20P to IEC 320 C5 laptop, IEC C13 computer power cable and molded with IEC C19 as PDU power cords are normal versions of America locking power cords with IEC connectors.
